Solar Cell Laser Scribing Machine Solar Cell Cutter
Machine Function
Solar cell laser scribing machine solar cell cutter is used to scribe or cut the Solar Cells and Silicon Wafers in solar PV industry, including the mono-si (mono crystalline silicon) and poly-si (poly crystalline silicon) solar cells and silicon wafer.
Technical Parameter
Model | OLS-2000S |
Laser wavelength | 1064nm |
Laser power | 30W |
Scribing width | 40μm |
Scribing speed | 500mm/s Adjustable |
Scribing accuracy | ±0.1mm |
Working area | 245x245mm |
Temperature control precision | 0.5°C |
Working power | 220V/50Hz/3kvA |
Working table | negative pressure absorbing and dust elimination |
Cooling method | Forced air cooling |
Detail picture
In 2021, our company has launched a new no water non-destructive solar cell laser scribing machine. For details, please click solar cell no water non-destructive laser scribing machine.
About us
Has The Following Required Machinery And Accessories
Ooitech “Turnkey Solution” Includes Factory Construction, Facility Layout, Raw Materials BOM guidance, Production Procedure assistance, Solar Power Station installation technical support Etc.
Ooitech focus on:
Supply 10MW-500MW Turnkey PV Production Line
Update the traditional PV line to the newest MBB solar panel production line.
Main machinery
