Solar Panel Tester Solar Panel Power Tester IV Tester Sun Simulator
Machine Function
Sun Solar Simulator is used to test the electric performance of Mono-Si or Poly-Si solar modules and record the results in files.
Technical Parameter
MODEL | OSMT-A | OSMT-B |
Lamp spectrum | In line with iec60904-9 spectral Irradiance distribution requirement(AM1.5) |
Light intensity | 700_1200W/M2 continuous adjustable |
Light intensity non-uniformity | ≤±2% 【A】 | ≤±3% |
Light intensity instability of irradiation(STI) | ≤±0.5% 【A】 | ≤±2% |
Light intensity instability Non-Uniformity of Irradiance(LTI) | ≤±2% | ≤±2% |
Test results consistency | ≤±0.5%【A】 | ≤±1% |
Single flash time | 10ms~40ms | 10ms |
Effective test range | 2400×1400mm/5W-650W |
Measuring voltage | 0-100V(resolution 1mV) |
Measuring current | 0-20A(resolution 1mA) |
Power Supply | AC220V/50HZ/2KVA |
Test parameters | Isc、Voc、Pmax、Vm、ImFF、EFF、Temp、Rs、Rsh |
Xenon Lamp service time | 100,000flash times |
Weight | 600kgs |
Detail picture
About US
Ooitech, One-stop Solution For Solar Module Manufacturing Equipment.
Has The Following Required Machinery And Accessories
Ooitech “Turnkey Solution” Includes: Factory Construction, Facility Layout, Raw Materials BOM guidance, Production Procedure assitance, Solar Power Station installation technical support Etc.
Ooitech focus on:
Supply 10MW-500MW Turnkey PV Production Line
Update the traditional PV line to the newest MBB solar panel production line.
Main machinery
Xenon lamp
PCB board
